Source
• Light source: JB-Lighting LED module, max. 800W LED Power Effects
• Animation wheel, horizontal and vertical, rotating in both directions, variable speed
• 2 gobo wheels with 7 gobos each, rotating, indexable, exchangeable
• 4-facett prism, rotating in both directions at variable speed
• Frost
• High-resolution iris diaphragm, pulse in different speed
• Zoom 12° - 32° and Focus
• Strobe effect, pulse and snap, speed up to 20 Hz
• Dimmer 0% - 100%
colour mixing
• RGB colour mixing
• Additional CTC channel
• Virtual colour wheel channel
• Pre-programmed white
• Rainbow effect in various speeds
control and programming
• Protocols: DMX-512
• JB-Lighting Wireless DMX on-board
• Stand-alone operation
• Built-in analyser for easy fault finding
construction
• Slide-in module
• Data in/out: Locking 3pin & 5pin XLR
• PowerCon in and out
Rigging
• 2x Omega brackets for quick and comfortable mounting in any direction
• Tilt transport locks
Electrical specifications
• Power consumption: max. 980 W
Mechanical specifications
• Height: 673 mm
• Width: 409 mm
• Depth: 308 mm
• Weight: 23,5 kg
