Power Source
|
100 - 240 V AC, 50/60 Hz (use of the supplied AC adapter)
|
|
Power Consumption
|
72 W
|
|
Current Consumption
|
Max. 3 A DC (when 24 V DC is supplied from the accessory AC adapter)
|
|
Carrier Frequency
|
Reception: Audio channel 1: 7.35 MHz
Audio channel 2: 8.10 MHz
Audio channel 3: 8.55 MHz
Audio channel 4: 9.15 MHz
Control channel: 6.45 MHz
Transmission: Audio channel: 1.95 MHz
|
|
Input
|
MIC: -60 dB (*2) , 600 Ω, unbalanced, φ6.3 mm phone jack (2P)
AUX: -20 dB (*2) , 10 kΩ, unbalanced, φ6.3 mm phone jack (2P)
|
|
Output
|
LINE: -10 dB (*2), 10 kΩ, unbalanced, φ6.3 mm phone jack (2P)
REC: -10 dB (*2), 10 kΩ, unbalanced, RCA pin jack
HEADPHONES: φ3.5 mm mini jack (3P:monaural)
|
|
Equalizer Input/Output
|
Input: -20 dB (*2), 10 kΩ, unbalanced, RCA pin jack
Output: -20 dB (*2), 10 kΩ, unbalanced, RCA pin jack
|
|
Number of ConnectableChairman/Delegate Units
|
64 units
|
|
Number of Connectable Infrared Transmitter/Receiver Units
|
Up to 4 units (with the use of distributor, up to 16 units connectable
when they are all TS-905, and up to 12 units when they are all TS-907, or TS-905 and TS-907 are used in combination)
|
|
Infrared Transmitter/Receiver I/O Terminal
|
BNC jacks
|
|
External Control Connection Terminal
|
D-sub connector (9P, male)/USB-B selectable
|
|
LED Indicator
|
Audio signal receiving indicators 1 - 4 CH, Data signal receiving indicator, External control priority indicator, External control communication indicator, Battery indicator (flashes when a Chairman/Delegate unit's battery nears complete discharge), Recording status indicator, Format in-progress indicator, Access Indicator, Internal memory status indicator, USB memory status indicator, Remaining internal memory capacity warning indicator, Remaining USB memory capacity warning indicator, Short-circuit indicator
|
|
Record Switch
|
Recording start button, Recording stop button, Format button
|
|
Recording Ports
|
USB-A (for USB memory devices) and USB Mini-B (for PCs)
|
|
Recording Function
|
Recordings can be made to a USB memory device (*3) or the internal memory.
Recording format: MP3 (MPEG-1 Audio Layer-3), monaural
Sampling frequency: 32 kHz, Bit rate: 128 kbps
|
|
Function Switch
|
Number of open microphones setting switch: 1/2/3/4
Mic-off setting switch: TIME OUT ON/OFF
Speech priority selector switch:
FIRST (First-in-first-out priority)
LATEST (Last-in-first-out priority)
FIRST:FIXED NEXT:LATEST (Priority fixed for the first unit, and last-in-first-out priority for all other subsequent units.)
FBS switch: AUTO/OFF/EXT
|
|
Operating Temperature
|
0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
|
|
Operating Humidity
|
90 %RH or less (no condensation)
|
|
Finish
|
Panel: Surface-treated steel plate, black, 30 % gloss, paint
|
|
Weight
|
2.8 kg (6.17 lb)
|
|
Accessory
|
AC adapter (Cord length: 1.8 m (5.91 ft) DC cord, and 2 m (6.56 ft) detachable AC cord)(*4) …1
|
|
Option
|
Rack mounting bracket: MB-TS920
|
