Power Source
|
24 V DC (supplied from the TS-D1000-MU Master control units (option), TS-D1000-SU Sub control units (option) or
TS-D1000-EX Extension units (option))
|
|
Power Consumption
|
1.5 W or less
|
|
Input
|
Microphone terminal: XLR-3-31 type
|
|
Output
|
Monitor speaker: 8 Ω, 0.4 W
Earphone: φ3.5 mm mini Jack (3P:monaural) ×2
|
|
Connecting Terminal
|
RJ45 connector ×2
|
|
LED Indicator
|
Power indicator, Speech indicator
|
|
Function
|
Speech function, Priority speech function, Earphone volume control (×2)
|
|
Operating Temperature
|
0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
|
|
Operating Humidity
|
90 %RH or less (no condensation)
|
|
Finish
|
Case: ABS resin, black, mat finish, paint
Speaker net: Steel plate, black, mat finish, paint
|
|
Dimensions
|
208.9 (W) × 71.3 (H) × 160.5 (D) mm (8.22" × 2.81" × 6.32")
|
|
Weight
|
880 g (1.94 lb)
|
|
Option
|
Standard microphone: TS-D1000-M1
Long microphone: TS-D1000-M2
|
