| Power Source |
100 - 240 V AC, 50/60 Hz (use of the supplied AC adapter) |
| Power Consumption |
72 W |
| Current Consumption |
Max. 3 A DC (when 24 V DC is supplied from the accessory AC adapter) |
| Carrier Frequency |
Reception: Audio channel 1: 7.35 MHz
Audio channel 2: 8.10 MHz
Audio channel 3: 8.55 MHz
Audio channel 4: 9.15 MHz
Control channel: 6.45 MHz
Transmission: Base language channel: 1.95 MHz
Translation language channel: 2.25 MHz |
| Input |
MIC 1 (Base Language): -60 dB*, 600 Ω, unbalanced, φ6.3 mm phone jack (2P)
MIC 2 (Translation Language): -60 dB*, 600 Ω, unbalanced, φ6.3 mm phone jack (2P)
AUX 1 (Base Language): -20 dB*, 10 kΩ, unbalanced, φ6.3 mm phone jack (2P)
AUX 2 (Translation Language): -20 dB*, 10 kΩ, unbalanced, φ6.3 mm phone jack (2P)
AUX 3 (Base and Translation Language): -20 dB*, 10 kΩ, unbalanced, φ6.3 mm phone jack (2P) |
| Output |
LINE: -20 dB*, 10 kΩ, unbalanced, φ6.3 mm phone jack (2P)
REC: -20 dB*, 10 kΩ, unbalanced, φ6.3 mm phone jack (2P), RCA pin jack
HEADPHONES: φ3.5 mm mini jack (3P:monaural) |
| External Equalizer |
Input: -20 dB*, 10 kΩ, unbalanced, RCA pin jack
Output: -20 dB*, 10 kΩ, unbalanced, RCA pin jack |
| Number of ConnectableChairman/Delegate Units |
192 units |
| Number of ConnectableExpansion Unit |
4 units (Up to 8 units connectable when using a distributor) |
| Expansion Unit I/O Terminal |
BNC jack |
| LED Indicator |
Voting result indicators 1 - 3 (7-segment LED, 3 digits), Power indicator, Audio signal receiving indicators 1 - 4 CH, Data signal receiving indicator, External control priority indicator, External control communication indicator, Battery indicator (Flashes in case of battery warning of Infrared
Conference unit), Short-circuit indicator |
| External Control ConnectionTerminal |
D-sub connector (9P, male)/USB-B selectable |
| Function Switch |
Simultaneous speaker No. setting switch: 1/2/3/4
Mic-off setting switch: TIME OUT ON/OFF
Speech priority selector switch: A/B/C
(A: First-in-first-out priority, B: Last-in-first-out priority, C: Fixed for the first unit, and last-in-first-out for
the subsequent units)
FBS selector switch: External equalizer/OFF/FBS AUTO/FBS MANUAL |
| Operating Temperature |
0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Operating Humidity |
90 %RH or less (no condensation) |
| Finish |
Panel: Surface-treated steel plate, gray metallic, paint, semi-gloss |
| Weight |
2.8 kg (6.17 lb) |
| Accessory |
AC adapter (Cord length: 1.8 m (5.91 ft) DC cord, and 2 m (6.56 ft) detachable AC cord)…1 |
| Option |
Rack mounting bracket: MB-TS900 |
