| Power Source |
24 V DC (supplied from the TS-918 Expansion Unit (option)) |
| Current Consumption |
Max. 60 mA |
| Modulation Method |
Frequency modulation |
| Carrier Frequency |
Transmission: Audio channel 1: 7.35 MHz
Audio channel 2: 8.10 MHz
Audio channel 3: 8.55 MHz
Audio channel 4: 9.15 MHz
Control channel: 6.45 MHz
Reception: Base language channel: 1.95 MHz
Translation language channel: 2.25 MHz |
| Input |
Microphone terminal: XLR-4-31 type
(dedicated for connecting the optional TS-903 or TS-904) |
| Output |
Monitor speaker: 8 Ω, 0.2 W
Headphone: φ3.5 mm mini Jack (3P:monaural) × 2 |
| Connection Terminal |
RJ45 connector |
| LED Indicator |
Speech indicator (flashes at communication failure),
Voting status indicators 1 -3, Power indicator (flashes at communication failure) |
| Function |
Monitor volume control, Headphone volume control, Voting function,
Monitor selector switch (MAIN/SUB) |
| Operating Temperature |
0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Operating Humidity |
90 %RH or less (no condensation) |
| Finish |
Top panel: ABS resin, gray metallic, paint, semi-gloss |
| Dimensions |
210 (W) × 68.6 (H) × 152 (D) mm (8.27" × 2.7" × 5.98") |
| Weight |
570 g (1.26 lb) |
| Option |
Microphone: TS-903, TS-904 (Select either one.) |
